Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
GDG5/100
GDG5/100 is a 5 amp, 250 volt AC time delay glass fuse designed for reliable circuit protection.This Eaton miniature fuse features a 5x20mm glass body with nickel-plated brass endcaps, providing a compact and durable design. It offers a 35,000 amp interrupting rating at 250VAC and complies with UL and CSA recognition, as well as SEMKO and VDE approvals. The fuse is designed to IEC 60127-2 standards for overcurrent protection in electronic circuits.
- Key Specifications
- Amperage: 5 Amps
- Voltage Rating: 250 Volts AC
- Fuse Type: Time Delay
- Body Material: Glass
- Physical Size: 5mm x 20mm
- Interrupting Rating: 35kA at 250VAC
- Mounting Type: Ferrule (cartridge)
- Certifications: UL Recognized, CSA Recognized, SEMKO, VDE
- Standards: IEC 60127-2
- Part Number: GDG5/100
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : GDG Series
- Type : GDG
- Voltage : 250
- Amperage : 5
- AIC rating : 35kA@250Vac
- Connection : Ferrule
- Diameter : 5
- UPC : 78200129537
- GTIN : 00782001295370
- Weight : 5.19
