GD2045 - Eaton 45A 480V 2 Pole Molded Case Circuit Breaker GD Frame 14kAIC at 480V

GD2045

GD2045 is a 2 pole molded case circuit breaker from Eaton's GD series, designed for reliable protection in commercial and industrial power distribution systems. This breaker features a 45 amp current rating, 480V AC maximum voltage, and a 14kAIC interrupt rating at 480V. It is suitable for cable-in/cable-out applications and reverse feed installations, with line and load side lug terminals for flexible wiring. The GD2045 uses a fixed thermal-magnetic trip unit for long time and instantaneous protection, and is non-interchangeable for added safety. It is UL listed and designed for panel mounting.

• Part Number: GD2045
• Manufacturer: Eaton
• Series/Frame: GD
• Amperage: 45A
• Maximum Voltage: 480V AC
• Poles: 2
• Interrupt Rating: 14kAIC @ 480V
• Mounting Type: Panel
• Terminal Type: Line & Load Side Lug
• Trip Unit: Fixed Thermal-Magnetic
• Certifications: UL Listed
• Application: Cable-In/Cable-Out, Reverse Feed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GD2045
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GD
• Voltage : 480
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : G Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679118153
• GTIN : 00786679118153
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4.88 in x 2 in (Length/Depth x Height x Width)
• Weight : 1.41
• Certification : UL Listed
