Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
GBA-1
GBA-1 is a 1-amp, 125V fast-acting pin-indicating cartridge fuse designed for overcurrent protection in electronic circuits.
The GBA-1 features a red indicating pin that signals when the fuse has blown, providing visual confirmation of a fault condition. This 1/4" x 1-1/4" (6.3 mm x 32 mm) miniature cylindrical fuse is constructed with a fiber tube body and nickel-plated brass endcaps for durability and reliable electrical contact. The fuse employs a clip termination style and is rated for fast-blow operation, making it ideal for sensitive electronic equipment requiring rapid response to overcurrent events.
- Amperage Rating: 1A
- Voltage Rating: 125V AC
- Fuse Type: Fast-Acting (Quick Blow)
- Size: 1/4" x 1-1/4" (6.3 mm x 32 mm)
- Indicator Style: Red Pin Indicating
- Termination: Clip
- Body Material: Fiber Tube
- Endcaps: Nickel-Plated Brass
- UL Standard: UL 248-14
- Application: Electronic Circuit Overcurrent Protection
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: GBA-1
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : GBA Series
- Type : GBA
- Voltage : 125
- Amperage : 1
- AIC rating : 10kA@125V
- Diameter : 0.25
- Barrels : 1
Product Data
- UPC : 051712714716
- GTIN : 00051712714716
- Dimensions : 0.25 in x 1.25 in x 0.25 in (Length/Depth x Height x Width)
- Weight : 0.86
