Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
GAB25
GAB25 is a fast-acting, ceramic miniature fuse designed for reliable circuit protection in a variety of electronic and electrical applications.
This fuse features a 25A current rating, 125V/250V AC voltage rating, and a 6x32mm (1/4" x 1-1/4") ferrule body style. It is constructed with a ceramic tube for durability and safety, and is suitable for use in nonrejection clip-mount fuse blocks. The GAB25 is part of the GAB series and is certified to CSA and UL standards, ensuring compliance with North American safety requirements.
Key Specifications
- Amperage: 25A
- Voltage: 125V AC (rated up to 250V AC)
- Poles: Single
- Mounting Type: Nonrejection clip
- Interrupt Rating: 10 kA @ 125V AC, 400A @ 250V AC
- Series/Frame: GAB Series, Miniature
- Trip Unit: Fast-acting
- Body Material: Ceramic
- Terminal Type: Ferrule
- Size: 6x32mm (1/4" x 1-1/4")
- Certifications: CSA, UL
- Visual Indication: Non-indicating
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: GAB25
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : GAB
- Voltage : 125
- Amperage : 25
- AIC rating : 400kA@125V
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
- Velocity : Fast Acting
Product Data
- UPC : 078200122417
- GTIN : 00782001224172
- Country of Origin : China
- Dimensions : x 1-1/2 in x
- Weight : 0.006
- Certification : CSA, UL
