Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
GAB1
GAB1 is a fast-acting miniature fuse from Eaton designed for supplemental circuit protection at 250VAC and 1 ampere rating.This Eaton GAB1 fuse features a ceramic cylindrical body measuring 6.3x32 mm with ferrule terminals and clip mounting. It has a fast-acting characteristic suitable for electronic applications, with an interrupt rating of 35A at 250VAC. The fuse is non-indicating, non-rejection type, and RoHS compliant.
- Amperage Rating: 1 A
- Voltage Rating: 250 VAC
- Fuse Size: 6.3 x 32 mm (1/4 x 1-1/4 inch)
- Mounting Type: Clip
- Terminal Type: Ferrule
- Fuse Class: Supplemental
- Speed/Characteristic: Fast-Acting
- Interrupt Rating: 35 A at 250 VAC
- Body Material: Ceramic
- Non-Indicating, Non-Rejection Type
- RoHS Compliant
Specifications
- Part Number: GAB1
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Type : GAB
- Voltage : 250
- Amperage : 1
- AIC rating : 35A@250V
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
- Velocity : Fast Acting
Product Data
- UPC : 78200176006
- GTIN : 00782001760069
- Country of Origin : China
- Dimensions : x 1-1/2 in x
- Weight : 0.006
- Certification : CSA, UL
