Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage
Description
GAB1/8
GAB1/8 is a fast-acting miniature fuse from Mersen Ferraz Shawmut designed for supplemental circuit protection at 250VAC and 0.125 amperes.This fuse features a ceramic body with a 1/4 inch diameter and 1-1/4 inch length, equipped with ferrule terminals and clip mounting for easy installation. It has a fast-acting characteristic suitable for electronic circuits, with an interrupt rating of 35 amperes and is UL listed and CSA certified.
- Amperage Rating: 0.125 A
- Voltage Rating: 250 VAC
- Fuse Class: Supplemental
- Speed/Characteristic: Fast-Acting
- Fuse Size: 1/4 x 1-1/4 inch (6.3 x 32 mm)
- Body Material: Ceramic
- Mounting Type: Clip
- Terminal Type: Ferrule
- Interrupt Rating: 35 AIC
- Certifications: UL Listed, CSA Certified
- Non-Indicating, Non-Rejection Type
Specifications
- Part Number: GAB1/8
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage
- Type : GAB
- Voltage : 250
- Amperage : 1
- AIC rating : 35A@250V
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
- Velocity : Fast Acting
Product Data
- Weight : 0.1
