- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWX-90A
FWX-90A is a high-speed semiconductor fuse from Eaton designed for 90 Amp current rating and 250 Volt AC/DC voltage rating.FWX-90A features a stud mounting style with bolt-down termination, providing reliable circuit protection with a 200kA interrupting rating at 250VAC and 50kA at 250VDC. It is UL recognized and suitable for high-speed fuse applications requiring fast acting characteristics.
- Current Rating: 90 Amps
- Voltage Rating: 250 VAC/VDC
- Interrupting Rating: 200,000 AIC at 250 VAC
- Interrupting Rating: 50,000 AIC at 250 VDC
- Mounting Type: Stud Mount
- Termination Style: Bolt Down
- Fuse Type: Semiconductor, High Speed
- Physical Size: Approximately 1 inch diameter by 3.13 inches length
- UL Recognized
- Non-Indicating
Specifications
- Part Number: FWX-90A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWX Series
- Type : FWX
- Voltage : 250
- Amperage : 90
- AIC rating : 200kA@250V
- Connection : Stud
- Diameter : 1.22
- Barrels : 1
Product Data
- UPC : 051712150620
- GTIN : 00051712150620
- Dimensions : 3.11 in x 3.11 in x 1.23 in (Length/Depth x Height x Width)
- Weight : 0.3
