Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWX-70A
FWX-70A is a high speed semiconductor fuse from Eaton Bussmann designed for fast-acting circuit protection.
This FWX series fuse features a 70 ampere rating, 600 volts AC interrupting capacity, and 250 volts DC rating. It is stud mounted with blade end terminals and offers a high interrupt rating of 200 kAIC at 600 VAC and 50 kAIC at 250 VDC. The fuse is non-indicating and UL recognized, suitable for semiconductor and specialty applications requiring reliable fast blow protection.
- Key Specifications
- Amperage: 70A
- Voltage Rating: 600 VAC / 250 VDC
- Interrupt Rating: 200 kAIC at 600 VAC, 50 kAIC at 250 VDC
- Mounting Type: Stud Mount
- Fuse Type: High Speed Semiconductor
- Body Style: Blade end X blade end
- Series: FWX
- Trip Unit: Fast Acting
- Certifications: UL Recognized
- Non-Indicating
- Dimensions: Approximately 3.13 in length x 1.22 in diameter
- Part Number: FWX-70A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWX Series
- Type : FWX
- Voltage : 250
- Amperage : 70
- AIC rating : 200kA@250V
- Connection : Stud
- Diameter : 1.22
- Barrels : 1
- UPC : 051712150606
- GTIN : 00051712150606
- Country of Origin : Mexico
- Dimensions : 3.11 in x 3.11 in x 1.23 in (Length/Depth x Height x Width)
- Weight : 0.3
- Certification : CE, CSA Certified, UL Recognized
