FWX-700A - Eaton Bussmann Series High Speed Fuse 700A 600V Stud Mount 200kAIC

FWX-700A

FWX-700A is an Eaton Bussmann series high speed fuse designed for reliable circuit protection.This 700A, 600V fuse features a stud mounting method and a high interrupt rating of 200 kAIC at 600 VAC and 50 kAIC at 250 VDC. It has blade end x blade end connections and is non-indicating.

Key Specifications
• Amperage Rating: 700A RMS
• Voltage Rating: 600 V AC
• Interrupt Rating: 200 kAIC at 600 VAC, 50 kAIC at 250 VDC
• Mounting Type: Stud
• Connection Type: Blade end x blade end
• Fuse Indicator: Non Indicating
• Dimensions: 5.4 in length, 2.2 in height, 2.1 in width
• Certifications: UL Recognized, CSA Certified, RoHS Compliant, CE Marked
• Watt Losses: 72 W
• Weight: 0.8 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWX-700A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWX Series
• Type : FWX
• Voltage : 250
• Amperage : 700
• AIC rating : 200kA@250V
• Connection : Stud
• Diameter : 2
• Barrels : 1

Product Data

• UPC : 051712150750
• GTIN : 00051712150750
• Country of Origin : Mexico
• Dimensions : 5.4 in x 2.2 in x 2.1 in (Length/Depth x Height x Width)
• Weight : 0.8
