FWX-400A - Eaton Bussmann 400A 600V High Speed Fuse Stud Mount 200kAIC

FWX-400A

FWX-400A is a high speed fuse from Eaton Bussmann series rated at 400 amps and 600 volts designed for stud mounting.This fast-acting fuse features a blade end to blade end connection, non-indicating design, and a high interrupt rating of 200 kAIC at 600 VAC and 50 kAIC at 250 VDC. It is RoHS compliant, UL recognized, CSA certified, and CE marked, suitable for semiconductor protection and other high-speed applications.

Key Specifications
• Amperage: 400A RMS
• Voltage Rating: 600V AC, 250V DC
• Interrupt Rating: 200 kAIC at 600 VAC, 50 kAIC at 250 VDC
• Mounting Type: Stud
• Fuse Type: High Speed, Fast Acting
• Connection: Blade end x blade end
• Fuse Indicator: Non Indicating
• Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
• Weight: 0.46 lb
• Length: 4.3 in
• Width: 1.62 in
• Height: 1.63 in

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWX-400A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWX Series
• Type : FWX
• Voltage : 250
• Amperage : 400
• AIC rating : 200kA@250V
• Connection : Stud
• Diameter : 1.5
• Barrels : 1

Product Data

• UPC : 051712150712
• GTIN : 00051712150712
• Country of Origin : Mexico
• Dimensions : 4.3 in x 1.63 in x 1.62 in (Length/Depth x Height x Width)
• Weight : 0.46
• Certification : CE, CSA Certified, UL Recognized
