Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWX-225A
FWX-225A is a high speed fuse from Eaton's Bussmann series designed for 225A RMS current and 600V voltage rating with stud mounting.FWX-225A features a blade end to blade end connection, non-indicating design, and a high interrupt rating of 200 kAIC at 600 VAC and 50 kAIC at 250 VDC. It is UL Recognized, CSA Certified, CE Marked, and RoHS Compliant, suitable for industrial electrical protection applications.
- Amperage Rating: 225A RMS
- Voltage Rating: 600V AC, 250V DC
- Interrupt Rating: 200 kAIC AC, 50 kAIC DC
- Mounting Type: Stud
- Connection: Blade end x blade end
- Fuse Indicator: Non-Indicating
- Series: Bussmann FWX
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
- Physical Size: Approx. 4.3 in length, 1.63 in height, 1.62 in width
- Weight: 0.46 lb
Specifications
- Part Number: FWX-225A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWX Series
- Type : FWX
- Voltage : 250
- Amperage : 225
- AIC rating : 200kA@250V
- Connection : Stud
- Diameter : 1.5
- Barrels : 1
Product Data
- UPC : 051712153973
- GTIN : 00051712153973
- Country of Origin : Mexico
- Dimensions : 4.3 in x 1.63 in x 1.62 in (Length/Depth x Height x Width)
- Weight : 0.46
