Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWX-20A14F
FWX-20A14F is a 20 amp, 600 volt Class J fast-acting fuse from Eaton designed for reliable circuit protection.This fuse features a current-limiting design with a high interrupting rating of 300,000 amps at 600 volts AC, ensuring safe interruption of high fault currents. It is a cartridge-style fuse suitable for use in industrial and commercial electrical systems requiring Class J fuses.
- Key Specifications
- Amperage: 20 A
- Voltage Rating: 600 V AC
- Fuse Type: Class J
- Trip Characteristic: Fast-Acting
- Interrupting Rating: 300,000 A at 600 V AC
- Mounting Type: Cartridge
- Manufacturer: Eaton
- Part Number: FWX-20A14F
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWX Series
- Type : FWX
- Voltage : 250
- Amperage : 20
- AIC rating : 200kA@250V
- Connection : Ferrule
- Diameter : 0.56
- Class Rating : aR
- Barrels : 1
- UPC : 051712795586
- GTIN : 00051712795586
- Country of Origin : India
- Dimensions : 55 mm x 32 mm x 73 mm (Length/Depth x Height x Width)
- Weight : 0.04669
- Certification : CE, CSA Certified, UL Recognized
Specifications
