Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWX-125A
FWX-125A is a high speed semiconductor fuse from Eaton Bussmann series rated at 125A and 250V with stud mounting.This fuse features a 200 kA interrupting rating at 250 VAC and 50 kA at 250 VDC, blade end x blade end connection, and non-indicating design. It is UL Recognized, CSA Certified, CE Marked, and RoHS Compliant, suitable for protecting semiconductor devices in industrial applications.
- Amperage: 125A RMS
- Voltage Rating: 250 VAC/VDC
- Interrupt Rating: 200 kAIC at 250 VAC, 50 kAIC at 250 VDC
- Mounting Type: Stud
- Connection: Blade end x blade end
- Fuse Indicator: Non Indicating
- Series: Bussmann FWX
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
- Watt Losses: 12.5 W
- Physical Size: Approx. 3.11 in length, 1.23 in width
Specifications
- Part Number: FWX-125A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWX Series
- Type : FWX
- Voltage : 250
- Amperage : 125
- AIC rating : 200kA@250V
- Connection : Stud
- Diameter : 1.22
- Barrels : 1
Product Data
- UPC : 051712150644
- GTIN : 00051712150644
- Country of Origin : Mexico
- Dimensions : 3.11 in x 3.11 in x 1.23 in (Length/Depth x Height x Width)
- Weight : 0.3
- Certification : CE, CSA Certified, UL Recognized
