FWP-90B - Cooper Bussmann Eaton 90A 700V Semiconductor High Speed Fuse Stud Mount

FWP-90B

FWP-90B is a Cooper Bussmann Eaton high speed semiconductor fuse rated for 90 amps and 700 volts AC/DC with stud mounting.

This fast-acting fuse features a cylindrical body with blade end terminals and offers a high interrupting rating of 200,000 AIC at 700 VAC and 50,000 AIC at 700 VDC. It is UL Recognized, CSA Certified, CE Marked, and RoHS Compliant, suitable for protecting DC common bus, DC drives, and power converters/rectifiers. The fuse has a compact size of approximately 3/4 inch diameter by 4.406 inches length and is designed for reliable semiconductor protection with a class aR utilization category.

• Amperage: 90 A
• Voltage Rating: 700 VAC/VDC
• Interrupting Rating: 200 kA AC, 50 kA DC
• Mounting Type: Stud Mount
• Fuse Type: High Speed Semiconductor
• Body Style: Cylindrical
• Terminal Type: Blade End
• Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
• Utilization Category: Class aR
• Dimensions: 0.947 in diameter x 4.406 in length

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWP-90B
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWP Series
• Type : FWP
• Voltage : 700
• Amperage : 90
• AIC rating : 200kA@700V
• Connection : Stud
• Diameter : 0.95
• Barrels : 1

Product Data

• UPC : 051712796033
• GTIN : 00051712796033
• Country of Origin : Hungary
• Dimensions : 112 mm x 25 mm x 25 mm (Length/Depth x Height x Width)
• Weight : 0.2484
• Certification : CE, CSA Certified, UL Recognized
