FWP-80B - Eaton Bussmann High Speed Semiconductor Fuse 80A 700V AC/DC Stud Mount 200kA Interrupt

FWP-80B

FWP-80B is a high speed semiconductor fuse from Eaton Bussmann designed for fast acting circuit protection.This fuse features an 80 ampere rating, 700 volts AC/DC voltage rating, and a stud mounting type. It has a high interrupting rating of 200,000 AIC at AC and 50,000 AIC at 500 VDC, ensuring reliable protection in demanding applications. The fuse body measures 3/4" x 4.406" and is UL recognized for amperages from 35 to 800 amps.

Key Specifications
• Amperage: 80 A
• Voltage Rating: 700 V AC/DC
• Mounting Type: Stud Mount
• Interrupting Rating: 200,000 AIC AC, 50,000 AIC DC
• Fuse Type: High Speed Semiconductor
• Physical Size: 3/4" x 4.406" (22x58 mm)
• Series: FWP
• UL Recognition: Yes (35-800 A)
• Fast Acting
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FWP-80B
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWP Series
• Type : FWP
• Voltage : 700
• Amperage : 80
• AIC rating : 200kA@700V
• Connection : Stud
• Diameter : 0.95
• Barrels : 1



Product Data

• UPC : 051712796026
• GTIN : 00051712796026
• Country of Origin : Hungary
• Dimensions : 112 mm x 25 mm x 25 mm (Length/Depth x Height x Width)
• Weight : 0.2484
• Certification : CE, CSA Certified, UL Recognized
