Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWP-70B
FWP-70B is a Bussmann semiconductor fuse rated for 70 amps and 700 volts AC/DC with fast acting characteristics.FWP-70B features a stud mount design and a high interrupting rating of 200,000 AIC RMS. It is a Class GR, fast blow fuse with a ceramic body and single element construction, suitable for protecting semiconductor devices.
- Key Specifications
- Amperage: 70 Amps
- Voltage Rating: 700 VAC/VDC
- Interrupting Rating: 200,000 AIC RMS
- Fuse Class: GR Semiconductor
- Speed Type: Fast Acting (Fast Blow)
- Mounting Type: Stud Mount
- Body Material: Ceramic
- Length: 4.406 inches
- Shape: Cartridge Blade
- UL Recognized
Specifications
- Part Number: FWP-70B
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWP Series
- Type : FWP
- Voltage : 700
- Amperage : 70
- AIC rating : 200kA@700V
- Connection : Stud
- Diameter : 0.95
- Barrels : 1
Product Data
- UPC : 051712796019
- GTIN : 00051712796019
- Country of Origin : Hungary
- Dimensions : 112 mm x 25 mm x 25 mm (Length/Depth x Height x Width)
- Weight : 0.2484
- Certification : CE, CSA Certified, UL Recognized
