Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWP-500A
FWP-500A is a high speed fuse from the Eaton Bussmann FWP series, designed for reliable protection in demanding electrical systems. This fuse features a 500A RMS current rating, 250 Vac/dc voltage rating, and blade end x blade end connection with stud mounting. It is non-indicating and built for high interrupt capacity applications. The FWP-500A is engineered for fast-acting protection in semiconductor and industrial circuits. Its fiberglass body and bolt-on design provide durability and secure installation. The fuse is suitable for use with CHM series fuse blocks and offers robust performance in both AC and DC systems.
- Part Number: FWP-500A
- Manufacturer: Eaton Bussmann
- Amperage Rating: 500A RMS
- Voltage Rating: 250 Vac/dc, 700 Vdc
- Interrupt Rating: 200 kAIC Vac, 50 kAIC at 700 Vdc
- Mounting Type: Stud
- Connection: Blade end x blade end
- Series: FWP
- Fuse Indicator: Non Indicating
- Body Material: Fiberglass
- Body Style: Bolt On
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
Specifications
- Part Number: FWP-500A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWP Series
- Type : FWP
- Voltage : 700
- Amperage : 500
- AIC rating : 200kA@700V
- Connection : Stud
- Diameter : 2.5
- Barrels : 1
Product Data
- UPC : 051712150453
- GTIN : 00051712150453
- Country of Origin : Mexico
- Dimensions : 7.5 in x 2.55 in x 2.55 in (Length/Depth x Height x Width)
- Weight : 2.18
- Certification : CE, CSA Certified, UL Recognized
