Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWP-4A14F
FWP-4A14F is an Eaton Bussmann series high speed fuse designed for semiconductor protection and power conversion applications.
This 4 amp, 700 volt AC/DC fuse features a 14 x 51 mm ceramic cylindrical body with ferrule end connections. It has a high interrupt rating of 200 kAIC at AC voltage and 50 kA at DC voltage, class aR utilization category, and is non-indicating. The fuse offers low arc voltage, low energy let-through, and low watt losses, making it suitable for DC common bus, DC drives, power converters, and rectifiers. It is UL recognized, CSA certified, CE marked, and RoHS compliant.
- Amperage Rating: 4 A
- Voltage Rating: 700 V AC/DC
- Fuse Size: 14 x 51 mm
- Interrupt Rating: 200 kA AC, 50 kA DC
- Class: aR (semiconductor protection)
- Fuse Shape: Cylindrical ceramic
- Connection: Ferrule end x ferrule end
- Indicator: Non-indicating
- Material: Ceramic
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
- Application: Semiconductor, DC common bus, DC drives, power converters/rectifiers
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FWP-4A14F
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWP Series
- Type : FWP
- Voltage : 700
- Amperage : 4
- AIC rating : 200kA@700V
- Connection : Ferrule
- Diameter : 0.56
- Barrels : 1
Product Data
- UPC : 05171279512
- GTIN : 00051712795128
- Dimensions : 52 mm x 15 mm x 15 mm (Length/Depth x Height x Width)
- Weight : 0.04692
