Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWP-450A
FWP-450A is a Cooper Bussmann Eaton high speed fuse rated for 450A and 250 Vac/dc with blade end x blade end connection and stud mounting.This fuse features a 450 amp RMS rating, 250 volts AC/DC voltage rating, and interrupt ratings of 200 kAIC at AC and 50 kAIC at 700 Vdc. It is a non-indicating, fast-acting fuse from the Bussmann FWP series designed for high speed protection in power distribution applications. The fuse has a cylindrical ceramic body with blade terminals and stud mounting for secure installation. It is CE marked, RoHS compliant, CSA certified, and UL recognized.
- Key Specifications
- Amperage: 450A RMS
- Voltage: 250 Vac/dc
- Interrupt Rating: 200 kAIC AC, 50 kAIC DC at 700 Vdc
- Connection: Blade end x blade end
- Mounting Type: Stud mount
- Fuse Type: High speed, fast acting
- Body Type: Cylindrical ceramic
- Indicating: Non-indicating
- Certifications: CE Marked, RoHS Compliant, CSA Certified, UL Recognized
- Series: Bussmann FWP
Specifications
- Part Number: FWP-450A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWP Series
- Type : FWP
- Voltage : 700
- Amperage : 450
- AIC rating : 200kA@700V
- Connection : Stud
- Diameter : 2.5
- Barrels : 1
Product Data
- UPC : 051712150446
- GTIN : 00051712150446
- Country of Origin : Mexico
- Dimensions : 7.5 in x 2.55 in x 2.55 in (Length/Depth x Height x Width)
- Weight : 2.18
- Certification : UL, CE, CSA
