FWP-40A14F - Eaton Bussmann 40A 700V Fast Acting High Speed Fuse, Class aR, Ferrule End, 200kA Interrupt

FWP-40A14F

FWP-40A14F is a 40 amp fast acting high speed fuse from Eaton Bussmann designed for semiconductor protection with a 700 VAC/800 VDC voltage rating.This fuse features a cylindrical ceramic body, ferrule end terminals, and a holder mounting type, providing reliable interruption with a 200 kA interrupt rating at 700 VAC and 50 kA at 700 VDC. It belongs to the FWP series, Class aR, non-indicating, and is suitable for frequencies from 45 to 1000 Hz.

Key Specifications
• Amperage: 40 A
• Voltage Rating: 700 VAC / 800 VDC
• Interrupt Rating: 200 kA at 700 VAC, 50 kA at 700 VDC
• Fuse Type: Fast Acting High Speed
• Series: FWP
• Body Type: Cylindrical Ceramic
• Terminal Type: Ferrule End
• Mounting Type: Holder Mount
• Class: aR
• Frequency Rating: 45 to 1000 Hz
• Dimensions: 14x51 mm (0.56" Dia x 2" L)
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWP-40A14F
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWP Series
• Type : FWP
• Voltage : 700
• Amperage : 40
• AIC rating : 200kA@700V
• Connection : Ferrule
• Diameter : 0.56
• Barrels : 1

Product Data

• UPC : 005171279650
• GTIN : 00051712796507
• Country of Origin : India
• Dimensions : 51 mm x 15 mm x 15 mm (Length/Depth x Height x Width)
• Weight : 0.04646
• Certification : CE, CSA Certified, UL Recognized
