Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWP-350A
FWP-350A is a 350 Amp, 700 Volt AC semiconductor high speed fuse designed for stud mounting applications.This Eaton Bussmann series fuse features fast acting characteristics with a high interrupting rating of 200,000 AIC RMS at 700 VAC and 10,000 AIC at 700 VDC. It offers low arc voltage, low energy let-through, excellent DC performance, and superior cycling capability. The fuse measures approximately 1.5 inches by 5.09 inches and is UL recognized for safety and reliability.
- Amperage: 350 A
- Voltage Rating: 700 V AC
- Fuse Type: Semiconductor High Speed
- Mounting Type: Stud Mount
- Interrupting Rating: 200,000 AIC RMS (AC), 10,000 AIC (DC)
- Physical Size: 1.5" x 5.09"
- UL Recognized
- Low arc voltage and energy let-through
- Excellent DC performance
- Superior cycling capability
- North American style bolted tag design
Specifications
- Part Number: FWP-350A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWP Series
- Type : FWP
- Voltage : 700
- Amperage : 350
- AIC rating : 200kA@700V
- Connection : Stud
- Diameter : 2
- Barrels : 1
Product Data
- UPC : 051712150422
- GTIN : 00051712150422
- Country of Origin : Mexico
- Dimensions : 2.4 in x 5.4 in x 2.9 in (Length/Depth x Height x Width)
- Weight : 1.7
- Certification : CE, CSA Certified, UL Recognized
