FWP-125A - Eaton Bussmann 125A 700V High Speed Fuse, Blade End x Blade End, Stud Mount, 200kAIC

FWP-125A

FWP-125A is a high speed fuse from Eaton Bussmann series rated for 125 amps and 700 volts AC/DC with stud mounting.This fuse features a blade end to blade end connection, a 200 kA interrupting rating at 700 VAC, and 50 kA at 700 VDC. It is non-indicating and designed for high speed circuit protection applications. The fuse is UL recognized, CSA certified, CE marked, and RoHS compliant.

• Amperage Rating: 125A RMS
• Voltage Rating: 700 VAC/DC
• Interrupting Rating: 200 kAIC at 700 VAC, 50 kAIC at 700 VDC
• Connection Type: Blade end x blade end
• Mounting Method: Stud
• Fuse Indicator: Non Indicating
• Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
• Watt Losses: 28 W
• Product Dimensions: Approx. 5.3 in length, 1.58 in height, 1.57 in width

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWP-125A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWP Series
• Type : FWP
• Voltage : 700
• Amperage : 125
• AIC rating : 200kA@700V
• Connection : Stud
• Diameter : 1.5
• Barrels : 1

Product Data

• UPC : 051712150361
• GTIN : 00051712150361
• Country of Origin : Mexico
• Dimensions : 5.3 in x 1.58 in x 1.57 in (Length/Depth x Height x Width)
• Weight : 0.6
• Certification : CE, CSA Certified, UL Recognized
