FWP-1200A - Eaton Bussmann 1200A 700VAC High Speed Fuse

FWP-1200A

FWP-1200A is a North American style bolted tag high speed fuse link designed for semiconductor and DC circuit protection applications.

The Eaton Bussmann Series FWP-1200A delivers excellent DC performance with low arc voltage and minimal energy let-through (I2t). This cylindrical fuse features blade end x blade end connections and is rated for 1200 amperes at 700 VAC, with a breaking capacity of 200 kA RMS symmetrical at rated voltage and 50 kA at 700 VDC. Typical applications include DC common bus, DC drives, power converters, rectifiers, and reduced voltage starters. The fuse measures 4.250 inches in diameter by 10.844 inches in length and weighs 6.60 lbs.

• Rated Current: 1200 A
• Rated Voltage: 700 VAC
• Breaking Capacity: 200 kA RMS Sym (AC), 50 kA (700 VDC)
• Connection Type: Blade end x blade end
• Body Style: Round cylindrical
• Dimensions: 4.250 in diameter x 10.844 in length
• Weight: 6.60 lbs
• UL Recognized: JFHR2.E91958
• CSA Component Acceptance: Class 1422-90
• CE Certified
• Superior cycling capability
• Low energy let-through

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWP-1200A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWP Series
• Type : FWP
• Voltage : 700
• Amperage : 1200
• AIC rating : 200kA@700V
• Connection : Stud
• Diameter : 4.25
• Barrels : 1

Product Data

• UPC : 051712796095
• GTIN : 00051712796095
• Dimensions : 285 mm x 122 mm x 128 mm (Length/Depth x Height x Width)
• Weight : 12.6017
