Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWJ-80A
FWJ-80A is an Eaton Bussmann series high speed cylindrical fuse rated at 80 amperes, designed for protection of AC and DC drives, power converters, rectifiers, and variable speed drives. FWJ-80A delivers reliable overcurrent protection with multiple interrupt ratings depending on voltage class and amperage range. This high speed fuse features blade end to blade end stud mounting configuration and is engineered for fast response in demanding industrial applications.
- Amperage Rating: 80A
- Interrupt Rating: 25 kAIC (35-200A)
- Interrupt Rating: 100 kAIC (250-2000A)
- Interrupt Rating: 50 kAIC at 800 Vdc (35-200A, 450-600A)
- Fuse Type: High Speed Cylindrical
- Mounting: Blade End x Blade End Stud
- Series: Eaton Bussmann FWJ
- Application: AC and DC Drives, Power Converters, Rectifiers, Variable Speed Drives
Specifications
- Part Number: FWJ-80A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWJ Series
- Type : FWJ
- Voltage : 1000
- Amperage : 80
- AIC rating : 25kA@1000V
- Connection : Stud
- Diameter : 1.13
- Barrels : 1
Product Data
- UPC : 051712796170
- GTIN : 00051712796170
- Country of Origin : Hungary
- Dimensions : 126 mm x 29 mm x 29 mm (Length/Depth x Height x Width)
- Weight : 0.44942
- Certification : CE, UL Recognized
