Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-90B
FWH-90B is a 90 Amp, 500 Volt AC semiconductor high speed fuse designed for stud mount applications.FWH-90B offers high interrupting ratings of 200,000 AIC RMS at AC and 50,000 AIC at 500 VDC, ensuring reliable protection for sensitive semiconductor devices. It features a compact 3/4" x 3.625" physical size and is UL recognized for 35 through 800 amperes. This fuse provides superior current interruption performance with a bolt-down stud mounting style for secure installation.
- Amperage: 90 Amps
- Voltage Rating: 500 VAC / 500 VDC
- Fuse Type: Semiconductor High Speed
- Mounting Type: Stud Mount
- Interrupting Rating: 200,000 AIC RMS AC, 50,000 AIC DC
- Physical Size: 3/4" x 3.625"
- Termination Style: Bolt Down
- UL Recognized (35-800A range)
- Series: Bussmann FWH
Specifications
- Part Number: FWH-90B
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 90
- AIC rating : 200kA@500V
- Connection : Stud
- Diameter : 0.94
- Barrels : 1
Product Data
- UPC : 051712795814
- GTIN : 00051712795814
- Country of Origin : India
- Weight : 1
- Certification : CSA Certified ,UL Recognized,CE Marked,RoHS Compliant
