Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-80A
FWH-80A is an Eaton Bussmann series high speed semiconductor fuse rated for 80 amps and 500 volts AC with stud mounting.This fuse features a high interrupting rating of 200,000 AIC RMS at AC and 50,000 AIC at 500 VDC, designed for fast and reliable circuit protection in semiconductor applications. It has a compact physical size of 3/4" x 3.625" and is UL recognized for amperages from 35 to 800 amps.
- Amperage: 80 Amps
- Voltage Rating: 500 Volts AC / 500 Volts DC
- Fuse Type: High Speed Semiconductor
- Mounting Type: Stud Mount
- Interrupting Rating: 200,000 AIC RMS AC
- Interrupting Rating: 50,000 AIC at 500 VDC
- Physical Size: 3/4" x 3.625"
- UL Recognized (35-800 Amps)
- Non-Indicating
- Series: Eaton Bussmann FWH
Specifications
- Part Number: FWH-80A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- AIC rating : 200kA@500Vac
- Connection : Bolt-In
- Diameter : 0.75
- Barrels : 1
Product Data
- UPC : 051712150064
- GTIN : 00051712150064
- Country of Origin : Mexico
- Dimensions : 4.6 in x 1.12 in x 1.8 in (Length/Depth x Height x Width)
- Weight : 0.2
- Certification : CE, CSA Certified, UL Recognized
