2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-800A
FWH-800A is an Eaton semiconductor high speed fuse rated for 800 Amps and 500 Volts AC/DC with blade terminal connections.FWH-800A provides reliable circuit protection with a high interrupting rating of 200kAIC at 500VAC and 50kAIC at 500VDC. It features a stud mounting type and is UL recognized for amperages from 35 to 800A. This fuse is designed for high-speed operation in semiconductor applications, ensuring fast and safe interruption of fault currents.
- Manufacturer: Eaton
- Series: FWH
- Amperage: 800A
- Voltage: 500VAC / 500VDC
- Interrupting Rating: 200kAIC at 500VAC, 50kAIC at 500VDC
- Mounting Type: Stud Mount
- Terminal Connection: Blade
- Fuse Type: Semiconductor High Speed
- UL Recognized (35-800A)
- Physical Size: Approx. 2" x 6.34"
Specifications
- Part Number: FWH-800A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 800
- AIC rating : 200kA@500V
- Connection : Stud
- Diameter : 2.5
- Barrels : 1
Product Data
- UPC : 051712150248
- GTIN : 00051712150248
- Country of Origin : Mexico
- Dimensions : 8 in x 2.59 in x 2.48 in (Length/Depth x Height x Width)
- Weight : 1.96
- Certification : CE, CSA Certified, UL Recognized
