Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-70A
FWH-70A is a high speed, non-indicating fuse from Eaton Bussmann Series, designed for reliable circuit protection in demanding applications.
This cartridge fuse features a blade end x blade end connection, making it suitable for high-speed interruption of overcurrents in semiconductor and power distribution circuits. It is engineered for robust performance with a high interrupting capacity and compact form factor.
-
Key Specifications
- Part Number: FWH-70A
- Manufacturer: Eaton
- Amperage: 70A
- Voltage: 700VAC/DC (also listed as 500VAC/DC in some sources; verify for your application)
- Poles: Single
- Mounting Type: Blade end x blade end (stud/bolt mount)
- Interrupt Rating: 200kAIC at 500VAC (verify for DC applications)
- Series/Frame: Bussmann FWH
- Trip Unit: Not applicable (fuse, not circuit breaker)
- Certifications: Not specified in available data
- Type: High speed (fast blow), non-indicating
- Physical Size: Approximately 3/4" x 3-5/8" (verify exact dimensions for your application)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FWH-70A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- AIC rating : 200kA@500Vac
- Connection : Bolt-In
- Diameter : 0.75
- Barrels : 1
Product Data
- UPC : 005171215005
- GTIN : 00051712150057
- Country of Origin : Mexico
- Dimensions : 4.6 in x 1.12 in x 1.8 in (Length/Depth x Height x Width)
- Weight : 0.2
