Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-50A
FWH-50A is an Eaton Bussmann series high speed fuse rated for 50 amps and 750 volts AC/DC with stud mounting.
This non-indicating semiconductor fuse provides fast-acting protection with a high interrupting rating suitable for industrial applications. It features a stud mount design for secure installation and complies with RoHS standards. The fuse measures approximately 0.88 in depth, 3.45 in height, and 0.93 in width, weighing 0.12 lb.
- Key Specifications
- Amperage Rating: 50 A
- Voltage Rating: 750 Vac, 750 Vdc
- Mounting Type: Stud
- Fuse Type: High Speed Semiconductor
- Fuse Indicator: Non Indicating
- Interrupting Rating: Up to 200,000 AIC RMS (AC), 50,000 AIC (DC)
- Compliance: RoHS Compliant
- Physical Dimensions: 0.88" x 3.45" x 0.93"
- Weight: 0.12 lb
- Packaging: Standard
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FWH-50A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Connection : Bolt-In
- Diameter : 0.75
- Barrels : 1
Product Data
- UPC : 005171215002
- GTIN : 00051712150026
- Country of Origin : Mexico
- Dimensions : 0.88 in x 3.45 in x 0.93 in (Length/Depth x Height x Width)
- Weight : 0.12
- Certification : RoHS Compliant
