Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-3A14F
FWH-3A14F is an Eaton Bussmann series high speed ferrule cylindrical fuse designed for reliable circuit protection in AC and DC applications. This compact cartridge fuse delivers excellent cycling capability, low arc voltage, and minimal energy let-through (I2t) in a 14 x 51 mm form factor suitable for finger-safe holders and blocks. Key Specifications
- Current Rating: 3A
- Voltage Rating: 500 VAC / 500 VDC
- Breaking Capacity: 200 kA RMS Sym at 500 VAC; 50 kA at 500 VDC
- Operating Class: aR (High Speed)
- Fuse Size: 14 x 51 mm Ferrule
- Termination Style: Ferrule End x Ferrule End
- Response Time: High Speed
- Certifications: UL Recognised, CE, CSA Component Acceptance File Class 1422-30
- Typical Applications: DC common bus, semiconductor protection, industrial control circuits
- Low watts loss design for compact installation
Specifications
- Part Number: FWH-3A14F
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 3
- AIC rating : 200kA@500V
- Connection : Ferrule
- Diameter : 0.56
- Barrels : 1
Product Data
- UPC : 05171279507
- GTIN : 00051712795074
- Dimensions : 14 mm x 14 mm x 51 mm (Length/Depth x Height x Width)
- Weight : 0.04692
