Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-35A
FWH-35A is a high speed semiconductor fuse from Eaton Bussmann series designed for reliable circuit protection.This fuse features a 35 ampere rating with voltage ratings of 1000 VAC and 800 VDC. It has a blade end x blade end connection type and is non-indicating. The FWH-35A is engineered for fast interruption of semiconductor circuits, providing high interrupting capacity and durability. It is suitable for stud mounting and complies with industry standards for safety and performance.
- Amperage: 35 A
- Voltage Rating: 1000 VAC, 800 VDC
- Mounting Type: Stud
- Connection: Blade end x blade end
- Fuse Type: High speed semiconductor fuse
- Interrupt Rating: High interrupting capacity (typically 200kA at 500VAC)
- Indication: Non-indicating
- Series: Bussmann FWH
- Dimensions: Approximately 3.18 in length, 0.81 in diameter
- Certifications: Meets Eaton Bussmann quality and safety standards
Specifications
- Part Number: FWH-35A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 35
- AIC rating : 200kA@500Vac
- Connection : Bolt-In
- Diameter : 0.75
- Barrels : 1
Product Data
- UPC : 051712150002
- GTIN : 00051712150002
- Country of Origin : Mexico
- Dimensions : 0.88 in x 3.45 in x 0.93 in (Length/Depth x Height x Width)
- Weight : 0.12
- Certification : CE, CSA Certified, UL Recognized
