FWH-300A - Eaton Bussmann 300A 500V Fast Acting Semiconductor Fuse, Bolt Mount, 2-Pole, 200kA Interrupt Rating

FWH-300A

FWH-300A is a fast acting semiconductor fuse manufactured by Eaton Bussmann designed for high speed circuit protection.This 300 amp, 500 volt fuse features a bolt mounting type with 2 pins and a ferrule style cartridge blade design. It offers a high interrupting rating of 200,000 amps RMS symmetrical at 500 VAC and 50,000 amps at 500 VDC. The fuse is lead free and compliant with CE, CSA, and UL certifications, suitable for semiconductor protection applications.

Key Specifications
• Amperage: 300 A
• Voltage Rating: 500 V AC/DC
• Mounting Type: Bolt
• Number of Poles: 2
• Interrupt Rating: 200 kA RMS Symmetrical at 500 VAC
• Fuse Type: Fast Acting Semiconductor
• Dimensions: 38.1 mm diameter x 110.2 mm length
• Certifications: CE, CSA, UL Recognized
• Lead Free and RoHS Compliant
• Power Dissipation: 51 W
• Series: FWH

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWH-300A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWH Series
• Type : FWH
• Voltage : 500
• Amperage : 300
• AIC rating : 200kA@500V
• Connection : Stud
• Diameter : 1.5
• Barrels : 1

Product Data

• UPC : 051712150163
• GTIN : 00051712150163
• Country of Origin : Mexico
• Dimensions : 1.69 in x 1.61 in x 4.52 in (Length/Depth x Height x Width)
• Weight : 0.52
• Certification : CE, CSA Certified, UL Recognized
