Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-275A
FWH-275A is a high speed fuse from the Eaton Bussmann series, designed for reliable circuit protection in demanding electrical applications. This fuse features a blade end design and is non-indicating, providing fast-acting protection for critical systems. The Eaton Bussmann FWH-275A fuse is rated for 275A RMS, 1000VAC, and 800VDC, with an interrupting rating of 200 kAIC at 1000 Vac and 50 kAIC at 500 Vdc. It is suitable for use in industrial, commercial, and utility power distribution systems where high-speed protection is required.
- Part Number: FWH-275A
- Manufacturer: Eaton Bussmann
- Amperage Rating: 275A RMS
- Voltage Rating: 1000VAC, 800VDC
- Interrupting Rating: 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
- Mounting Type: Blade End
- Indication Type: Non-Indicating
- Series: FWH High Speed Fuse
- Application: Power Distribution, Industrial Equipment
- Standards: UL Listed
- Operating Temperature: -40°C to 125°C
- Compliance: RoHS
Specifications
- Part Number: FWH-275A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 275
- AIC rating : 200kA@500V
- Connection : Stud
- Diameter : 1.5
- Barrels : 1
Product Data
- UPC : 051712153775
- GTIN : 00051712153775
- Country of Origin : Mexico
- Dimensions : 1.69 in x 1.61 in x 4.52 in (Length/Depth x Height x Width)
- Weight : 0.52
