Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-150A
FWH-150A is a 150 Amp, 500 Volt high speed semiconductor fuse with stud mounting designed for fast blow protection.This Bussmann Eaton fuse features a 200,000 AIC RMS interrupting rating at AC and 50,000 AIC at 500 VDC, ensuring reliable circuit protection for semiconductor devices. It has a compact cartridge size of approximately 1 inch diameter by 3.63 inches length and is non-indicating. The fuse is UL recognized for amperages 35A through 800A and constructed with ceramic material for durability.
- Amperage: 150 A
- Voltage Rating: 500 VAC/VDC
- Interrupting Rating: 200,000 AIC RMS AC, 50,000 AIC DC
- Speed: Fast Blow (High Speed)
- Mounting Type: Stud Mount
- Fuse Type: Semiconductor
- Dimensions: 1" diameter x 3.63" length
- Material: Ceramic
- UL Recognized (35A-800A)
- Non-indicating
- Class: 3AG Cartridge Blade
Specifications
- Part Number: FWH-150A
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWH Series
- Type : FWH
- Voltage : 500
- Amperage : 150
- AIC rating : 200kA@500Vac
- Connection : Bolt-In
- Diameter : 0.75
- Barrels : 1
Product Data
- UPC : 051712150118
- GTIN : 00051712150118
- Country of Origin : Mexico
- Dimensions : 3.701 in x 10 in x 1.181 in (Length/Depth x Height x Width)
- Weight : 0.34
- Certification : CE, CSA, UL
