Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWH-12A14F
FWH-12A14F is an Eaton Bussmann series high speed ferrule fuse designed for semiconductor and power converter protection. FWH-12A14F features a 12 ampere rating with a voltage rating of 500 volts AC/DC and a compact 14 x 51 mm cylindrical ceramic construction. It offers a high interrupt rating of 200 kA at AC voltage and 50 kA at DC voltage, ensuring reliable circuit protection in demanding applications.
- Key Specifications
- Amperage: 12 A
- Voltage Rating: 500 V AC/DC
- Fuse Size: 14 x 51 mm
- Interrupt Rating: 200 kA AC, 50 kA DC
- Fuse Type: High Speed Ferrule
- Connection: Ferrule end x ferrule end
- Material: Ceramic
- Utilization Category: aR (semiconductor protection)
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
- Application: Semiconductor, DC drives, power converters/rectifiers
- Watt Losses: 4.3 W
Specifications
- Part Number: FWH-12A14F
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 500
- Amperage : 12
- AIC rating : 200kA@500V
- Connection : Ferrule
- Diameter : 3.5
- Barrels : 1
Product Data
- UPC : 05171279569
- GTIN : 00051712795692
- Dimensions : 55 mm x 32 mm x 73 mm (Length/Depth x Height x Width)
- Weight : 0.04876
