Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWC-25A10F
FWC-25A10F is a high speed semiconductor fuse from Eaton Bussmann series designed for 25 ampere current and 600 volts AC/DC applications.FWC-25A10F features a cylindrical ceramic body with ferrule ends, offering a 200 kA interrupt rating at 600 VAC and 50 kA at 700 VDC. It is a Class aR fuse suitable for protecting semiconductor devices, DC common bus, DC drives, and power converters/rectifiers. The fuse is UL Recognized, CSA Certified, CE Marked, and RoHS Compliant.
- Key Specifications
- Amperage: 25 A
- Voltage Rating: 600 V AC/DC
- Interrupt Rating: 200 kA AC, 50 kA DC
- Fuse Size: 10 x 38 mm (cylindrical)
- Fuse Type: High speed semiconductor fuse
- Class: aR
- Material: Ceramic body
- Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
- Application: Semiconductor protection, DC drives, power converters
- Fuse Indicator: Non-indicating
- Pre-arc I2T: 60
- Watt Losses: 6 W
Specifications
- Part Number: FWC-25A10F
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FWC Series
- Type : FWC
- Voltage : 600
- Amperage : 25
- AIC rating : 200kA@600V
- Connection : Ferrule
- Diameter : 0.4
- Barrels : 1
Product Data
- UPC : 051712796477
- GTIN : 00051712796477
- Country of Origin : India
- Dimensions : 38 mm x 11 mm x 11 mm (Length/Depth x Height x Width)
- Weight : 0.02024
- Certification : CE, UL Recognized
