FWA-5A10F - Eaton Bussmann High Speed Cylindrical Fuse 5A 150V aR Class

FWA-5A10F

FWA-5A10F is an Eaton Bussmann series high speed cylindrical fuse designed for semiconductor protection, DC common bus, DC drives, and power converter applications. This ferrule end fuse delivers fast-acting protection with a 100 kAIC interrupt rating and Class aR utilization category for accompanied semiconductor protection. The fuse operates at 150 V AC/DC with a 5 A amperage rating and 10 x 38 mm construction size. Key Specifications

• Amperage Rating: 5 A
• Voltage Rating: 150 V AC/DC
• Interrupt Rating: 100 kAIC
• Breaking Capacity AC: 200 kA
• Breaking Capacity DC: 50 kA
• Fuse Class: aR (accompanied semiconductor protection)
• Fuse Size: 10 x 38 mm
• Connection: Ferrule end x ferrule end
• Material: Ceramic
• Certifications: UL Recognized, CSA Certified, CE Marked, RoHS Compliant
• Frequency Rating: 45-62 Hz
• Weight: 9.2 g

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWA-5A10F
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWA Series
• Type : FWA
• Voltage : 150
• Amperage : 5
• AIC rating : 100kA@150V
• Connection : Ferrule
• Diameter : 0.41
• Barrels : 1

Product Data

• UPC : 051712795197
• GTIN : 00051712795197
• Country of Origin : Hungary
• Dimensions : 39 mm x 11 mm x 11 mm (Length/Depth x Height x Width)
• Weight : 0.02116
• Certification : CE, UL Recognized
