Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FWA-250B
FWA-250B is a high speed semiconductor fuse from Eaton designed for reliable circuit protection in AC and DC applications.This Eaton Bussmann series FWA fuse features a 250 amp rating with a 150 volt AC/DC capacity, cylindrical body with stud mounting, and a 100 kA interrupting rating. It is a fast-acting fuse with blade end terminals and is UL recognized and CE marked for safety compliance.
- Amperage Rating: 250 A
- Voltage Rating: 150 V AC/DC
- Interrupting Rating: 100 kA
- Fuse Type: High Speed Semiconductor
- Body Style: Cylindrical
- Mounting Type: Stud Mount (M8)
- Terminal Type: Blade End
- Fuse Class: aR (semiconductor protection)
- Certifications: UL Recognized, CE Marked
- Non-Indicating Fuse
- Dimensions: 1 in Diameter x 2.656 in Length
- Utilization Category: aR
Specifications
- Part Number: FWA-250B
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 150
- Amperage : 250
- AIC rating : 100kA@150V
- Connection : Stud
- Diameter : 1
- Barrels : 1
Product Data
- UPC : 05171257784
- GTIN : 00051712577847
- Country of Origin : India
- Dimensions : 26 mm x 26 mm x 72 mm (Length/Depth x Height x Width)
- Weight : 0.1909
- Certification : CE, UL Recognized
