FWA-125B - Eaton 125 Amp 150 Volt High Speed Semiconductor Fuse Stud Mount

FWA-125B

FWA-125B is a 125 Amp high speed semiconductor fuse from Eaton's Bussmann series designed for reliable circuit protection.This fuse features a stud mounting type with blade end x blade end connections, suitable for AC and DC drives, power converters, and variable speed drives. It has a voltage rating of 150 Volts and an interrupting rating of up to 200 kA at AC and 20 kA at 150 Vdc. The fuse is UL recognized and CE certified, with a compact size of approximately 1.000 inch diameter by 2.656 inches length and a split crucible design.

Key Specifications
• Amperage: 125 A
• Voltage: 150 V
• Fuse Type: High Speed Semiconductor
• Mounting Type: Stud
• Connection: Blade end x blade end
• Interrupting Rating: 200 kA AC, 20 kA DC at 150 V
• Size: 1.000 in diameter x 2.656 in length
• Certifications: UL Recognized, CE
• Indicator: None
• Series: Bussmann FWA
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FWA-125B
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWA Series
• Type : FWA
• Voltage : 150
• Amperage : 125
• AIC rating : 100kA@150V
• Connection : Stud
• Diameter : 1
• Barrels : 1



Product Data

• UPC : 051712577816
• GTIN : 00051712577816
• Country of Origin : India
• Dimensions : 26 mm x 26 mm x 72 mm (Length/Depth x Height x Width)
• Weight : 0.2024
• Certification : CE, UL Recognized, Guide JFHR2, File 60314, CSA Certified LR12636
