FWA-1000A - Eaton Bussmann 1000A 150V High Speed Semiconductor Fuse, 200kAIC, Blade End X Blade End, Stud Mount

FWA-1000A

FWA-1000A is a high speed semiconductor fuse designed for reliable protection in demanding electrical applications. This Eaton Bussmann series fuse features a 1000A current rating and 150V AC/DC voltage rating, making it suitable for AC and DC drives, power converters, rectifiers, and variable speed drives. The fuse is non-indicating and features blade end X blade end stud mounting for secure installation. This cylindrical fuse is engineered for high interrupting capacity and fast response, providing critical protection for sensitive equipment. It is commonly used in industrial facilities, electrical assemblies, and critical power systems where reliability and safety are paramount.

• Part Number: FWA-1000A
• Manufacturer: Eaton Bussmann
• Amperage Rating: 1000A
• Voltage Rating: 150V AC/DC
• Interrupting Rating: 200kAIC (AC), 20kAIC @ 150VDC (70-800A), 100kAIC @ 80VDC (70-1000A)
• Mounting Type: Blade End X Blade End, Stud
• Series/Frame: FWA Series
• Fuse Indicator: Non Indicating
• Application: AC/DC Drives, Power Converters, Rectifiers, Variable Speed Drives
• Agency Approvals: UL Recognized, CE
• Physical Size: 1" x 3.476"
• Operating Class: aR, gR

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FWA-1000A
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FWA Series
• Type : FWA
• Voltage : 150
• Amperage : 800
• AIC rating : 200kA@150V
• Connection : Stud
• Diameter : 1.5
• Barrels : 1

Product Data

• UPC : 051712795463
• GTIN : 00051712795463
• Country of Origin : Hungary
• Dimensions : 89 mm x 39 mm x 39 mm (Length/Depth x Height x Width)
• Weight : 0.4416
• Certification : CE, UL Recognized
