Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
FW4200L
FW4200L is a Westinghouse molded case circuit breaker designed for reliable protection in low-voltage power distribution systems. This breaker features a robust 4-pole configuration and is rated for 200 amperes at 600 volts AC, making it suitable for a wide range of industrial and commercial applications.Engineered for durability and safety, the FW4200L offers fixed thermal-magnetic trip protection, ensuring consistent performance under varying load conditions. Its molded case construction provides excellent insulation and mechanical strength, while the bolt-on mounting design allows for secure installation in standard panelboards.
- Part Number: FW4200L
- Manufacturer: Westinghouse
- Amperage: 200A
- Voltage: 600V AC
- Poles: 4
- Mounting Type: Bolt-On
- Series/Frame: FD Series
- Trip Unit: Fixed Thermal-Magnetic
- Interrupt Rating: 30,000A Asymmetrical
- Construction: Molded Case
- Application: Industrial, Commercial
Specifications
- Part Number: FW4200L
- Manufacturer : Westinghouse
- Brand : Westinghouse
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C IEC
- Type : FW
- Voltage : 690
- Amperage : 200
- Phase : 3
- Poles : 4
- AIC rating : 40kA@415V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786679277201
- GTIN : 00786679277201
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 6.3
- Certification : IEC Rated
