Product Info
- Manufacturer:Gould Shawmut
- Sub-Category:Low Voltage
Description
FTS600R
FTS600R is a high-performance Class RK5 time delay fuse designed for reliable overcurrent protection in industrial and commercial applications. This fuse provides robust protection for motors, transformers, and service entrance equipment, featuring a rejection-style design to prevent incorrect replacements.Engineered for both AC and DC circuits, the FTS600R offers current limiting performance and is built to handle high inrush currents without nuisance tripping. The solid construction ensures durability and safety in demanding environments.
- 600 Amps
- 600 Volts AC
- Class RK5
- Time Delay
- Current Limiting
- Rejection Style Design
- AC and DC Rated
- Interrupting Rating: 200,000 AIC @ 600VAC
- Interrupting Rating: 100,000 AIC @ 600VDC
- Physical Size: 3 1/8" x 13 3/8"
- Cylindrical Body
- For Use with Recommended Fuse Blocks
Specifications
- Part Number: FTS600R
- Manufacturer : Gould Shawmut
- Brand : Gould Shawmut
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : Falt-Trap
- Type : FTS-R
- Voltage : 600
- Amperage : 600
- AIC rating : 200kA@600V
- Class Rating : RK5
- Barrels : 1
Product Data
- Weight : 6
