FTS50R - Gould Shawmut 50A 600V AC Class RK5 Time Delay Current Limiting Fuse

FTS50R

FTS50R is a 50A, 600V AC Class RK5 time delay current limiting fuse designed for reliable overcurrent protection in industrial and commercial power distribution systems. This fuse features a rejection style design to prevent replacement errors and is suitable for use in motor circuits, transformers, service entrance equipment, and branch circuits.Engineered for durability and safety, the FTS50R fuse offers time delay characteristics to handle motor starting and transformer inrush currents without nuisance tripping. The current limiting design ensures low peak let-thru current, providing enhanced protection for downstream equipment. The fuse is AC and DC rated, with a physical size of 1 1/16" x 5 1/2" and a rejection style body for secure mounting.

• 50A Amperage
• 600V AC Voltage Rating
• Class RK5
• Time Delay
• Current Limiting
• Rejection Style Design
• Physical Size: 1 1/16" x 5 1/2"
• AC and DC Rated
• Interrupting Rating: 200,000 AIC @ 600VAC
• DC Interrupting Rating: 20,000 AIC
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FTS50R
• Manufacturer : Gould Shawmut
• Brand : Gould Shawmut
• Category : Fuse
• Item Subcategory : Low Voltage
• Family : Falt-Trap
• Voltage : 600
• Amperage : 50
• AIC rating : 200kA@600V
• Class Rating : RK5
• Barrels : 1

Product Data

• Weight : 25
