FRS-R-5-6/10 - Bussmann, Cooper Bussmann, Eaton 5.6A 600VAC/300VDC Class RK5 Time Delay Fuse, Dual Element, 200kA Interrupt, Cylindrical

FRS-R-5-6/10

FRS-R-5-6/10 is a Bussmann, Cooper Bussmann, Eaton Class RK5 time-delay fuse designed for reliable circuit protection in demanding applications.

This dual-element, current-limiting fuse offers a 5.6A amperage rating, 600VAC/300VDC voltage rating, and a high 200kA interrupting capacity. It is suitable for use in combination starters, machinery disconnects, motor control centers, and power panelboards. The cylindrical body measures 0.81" diameter x 5" length, and the fuse features a time-delay characteristic for enhanced motor and transformer protection.

Key Specifications
• Part Number: FRS-R-5-6/10
• Manufacturer: Bussmann, Cooper Bussmann, Eaton
• Amperage: 5.6A
• Voltage: 600VAC/300VDC
• Poles: Not specified (fuse, not a breaker)
• Mounting Type: Fuse clip (cylindrical cartridge)
• Interrupt Rating: 200kA
• Series/Frame: Class RK5
• Trip Unit: Dual element, time-delay
• Certifications: UL Listed (Class RK5)
• Body Size: 0.81" dia x 5" length
• Application: Motor circuits, transformers, combination starters

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FRS-R-5-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Fusetron
• Type : FRS-R
• Voltage : 600
• Amperage : 5
• AIC rating : 200kA@600V
• Diameter : 0.81
• Class Rating : RK5
• Barrels : 1

Product Data

• UPC : 051712508230
• GTIN : 00051712508230
• Country of Origin : Mexico
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.141
• Certification : CE, CSA Certification Class 1422-01, UL 248-12 Guide JDDZ
