Product Info
- Manufacturer:Eaton
Description
FPS3080L
FPS3080L is an 80 amp, 600 volt, 3-pole molded case circuit breaker from Eaton Cutler Hammer's FP frame series.This heavy-duty thermal magnetic circuit breaker features a fixed trip unit and is rated for interrupting currents of 65kA at 240 VAC, 35kA at 480 VAC, and 18kA at 600 VAC. It is designed for panel mounting with standard line and load terminals and complies with UL 489 and CSA C22.2 certifications.
- Key Specifications
- Amperage: 80A
- Voltage Rating: 600 VAC, 50/60 Hz
- Number of Poles: 3
- Interrupting Rating: 65kA at 240 VAC, 35kA at 480 VAC, 18kA at 600 VAC
- Frame Type: FP
- Trip Unit: Fixed Thermal Magnetic
- Mounting Type: Panel Mount
- Terminal Connection: Standard Line and Load
- Certifications: UL 489, CSA C22.2
- Dimensions: 4.13" W x 3.38" D x 6" H
Specifications
- Part Number: FPS3080L
- Manufacturer : Eaton
- Brand : Cutler Hammer
Product Data
- UPC : 78667918892
- Country of Origin : Dominican Republic
- Dimensions : 7.5 in x 6 in x 5 in (Length/Depth x Height x Width)
- Weight : 5
