FNQ-R-3/4 - Bussmann Cooper Eaton Class CC Time-Delay Fuse, 3/4A, 600VAC, Current-Limiting, UL Listed, CSA Certified, RoHS Compliant

FNQ-R-3/4

FNQ-R-3/4 is a Bussmann, Cooper, Eaton Class CC current-limiting, time-delay fuse designed for advanced circuit protection.

This fuse provides reliable overcurrent protection in a compact, industry-standard Class CC package, featuring a time-delay characteristic to withstand temporary inrush currents without nuisance tripping. It is suitable for a wide range of industrial and commercial applications where robust, current-limiting protection is required.

Key Specifications
• Amperage: 3/4A (750mA)
• Voltage: 600VAC
• Poles: Not applicable (fuse)
• Mounting Type: Not specified (standard fuse clip/block)
• Interrupt Rating: 200kA AC RMS Symmetrical
• Series/Frame: FNQ-R, Class CC
• Trip Unit: Not applicable (fuse)
• Certifications: UL Listed (Std. 248-4, Class CC, Guide JDDZ, File E4273), CSA Certified (Class CC, Class 1422-01, File 53787–HRC-MISC), CE, RoHS compliant
• Type: Time-delay (slow blow)
• DC Rating: Not rated for this amperage (300VDC for 15A & 20A only)
• Catalog Number: FNQ-R-3/4

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNQ-R-3/4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Medium Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712496933
• GTIN : 00051712496933
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
