FNQ-R-3-2/10 - Eaton Bussmann 3.2A 600V Class CC Time Delay Fuse, 200kA Interrupt, Cylindrical, Holder Mount

FNQ-R-3-2/10

FNQ-R-3-2/10 is a Bussmann Eaton Class CC time delay fuse rated at 3.2 amps and 600 volts AC with a 200,000 amp interrupting rating.This 3.2A 600V fuse features a cylindrical melamine tube body, ferrule end terminals, and is designed for holder mounting. It provides current limiting high inrush protection with a 12 second response time at 200% overload. The fuse is UL 248-4 listed, CSA certified, and CE compliant for reliable circuit transformer protection.

Key Specifications
• Amperage: 3.2 A
• Voltage Rating: 600 VAC
• Interrupt Rating: 200,000 AIC @ 600 VAC
• Class: CC
• Fuse Type: Time Delay, Current Limiting High Inrush
• Body Type: Cylindrical Melamine Tube
• Terminal Type: Ferrule End
• Mounting Type: Holder Mount
• Response Time: 12 seconds at 200% overload
• Certifications: UL 248-4, CSA, CE
• Dimensions: 13/32 inch diameter x 1-1/2 inch length
• Rejection Type: Rejection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNQ-R-3-2/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712150927
• GTIN : 00051712150927
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.015
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
