FNQ-R-3/10 - Eaton Bussmann Class CC Time Delay Fuse 0.3A 600VAC 200kA Interrupt Rating

FNQ-R-3/10

FNQ-R-3/10 is a Bussmann Eaton Class CC time-delay fuse rated for 0.3 amperes and 600 volts AC with a 200kA interrupt rating.This fuse features a cylindrical cartridge design with a 1.5 inch length and 0.41 inch diameter. It is a current-limiting, slow-blow fuse suitable for protecting branch circuits with high inrush currents. The FNQ-R series is UL listed, CSA certified, CE marked, and RoHS compliant. It is designed for holder mounting and provides reliable protection in industrial and commercial electrical applications.

Key Specifications
• Amperage: 0.3 A
• Voltage Rating: 600 VAC
• Interrupt Rating: 200 kA
• Fuse Class: CC
• Speed: Time Delay / Slow Blow
• Mounting Type: Holder Mount
• Dimensions: 1.5 in length x 0.41 in diameter
• Approvals: UL, CSA, CE, RoHS
• Current Limiting: Yes
• Body Type: Cylindrical Cartridge
• Series: FNQ-R

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNQ-R-3/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712496902
• GTIN : 00051712496902
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.015
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
