FNQ-R-3-1/2 - Eaton Bussmann Class CC Time-Delay Fuse 3.5A 600V 200kA Interrupting Rating Rejection Style

FNQ-R-3-1/2

FNQ-R-3-1/2 is an Eaton Bussmann Class CC time-delay fuse rated for 3.5 amps and 600 volts AC with a 200kA interrupting rating. This fuse features a dual-element current limiting design with a rejection style for secure mounting in compatible fuse holders. It provides reliable line protection for small control transformers, industrial control, and branch circuits with a 12-second response time at 200% overload. The fuse is RoHS compliant and CE marked, constructed with a melamine tube and ferrule end connections.

Key Specifications
• Amperage: 3.5 A
• Voltage Rating: 600 V AC
• Interrupting Rating: 200 kA
• Class: Class CC
• Fuse Type: Time-Delay, Dual-Element
• Mounting Type: Rejection Style
• Response Time: 12 seconds at 200% overload
• Connection: Ferrule end x ferrule end
• Material: Melamine tube
• Certifications: RoHS Compliant, CE Marked
• Application: Line protection, small control transformers, industrial control, branch circuits
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FNQ-R-3-1/2
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1



Product Data

• UPC : 051712496995
• GTIN : 00051712496995
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.015
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
