FNQ-R-1-6/10 - Eaton Bussmann Class CC Time-Delay Fuse 1.6A 600V 200kA Interrupt Rating Cartridge

FNQ-R-1-6/10

This 1.6 amp fuse features a 600 VAC voltage rating, 200kA interrupting rating, and a rejection style cartridge body for secure mounting. It provides reliable line protection with a 12-second response time at 200% overload and is RoHS compliant and CE marked. The fuse has ferrule end connections and a melamine tube construction, suitable for small control transformers and motor control applications.

Key Specifications
• Amperage: 1.6 A
• Voltage Rating: 600 VAC
• Interrupt Rating: 200 kA
• Fuse Class: Class CC
• Fuse Type: Time-Delay, Dual-Element, Current Limiting
• Mounting Type: Cartridge, Rejection Style
• Connection: Ferrule end x ferrule end
• Response Time: 12 seconds at 200% overload
• Material: Melamine tube
• Certifications: CE Marked, RoHS Compliant
• Size: 13/32 inch diameter x 1.5 inch length

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: FNQ-R-1-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 1
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1



Product Data

• UPC : 051712496964
• GTIN : 00051712496964
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.015
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
